| Aircraft |
|
Takeoff Weight (with propellers) |
Approx. 1850 g*
* The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. |
| Max Takeoff Weight |
2090 g |
| Dimensions |
377.7 × 416.2 × 212.5 mm (L×W×H, without propellers) |
| Wheelbase |
Diagonal: 498.5 mm
Front Motor L-R: 383.0 mm
Rear Motor L-R: 343.0 mm
Front-Rear: 341.6 mm |
| Max Ascent Speed |
6 m/s (Normal Mode)
10 m/s (Sport Mode) |
| Max Descent Speed |
6 m/s (Normal Mode)
8 m/s (Sport Mode) |
| Max Horizontal Speed |
Normal Mode (Obstacle Sensing Enabled): 15 m/s forward, 12 m/s backward, 10 m/s sideways
Sport Mode: 21 m/s forward, 19 m/s backward, 15 m/s sideways
* When used with DJI Dock, only Normal Mode is supported. |
| Max Takeoff Altitude |
6500 m |
| Max Flight Time |
54 minutes
Measured at 12 m/s forward flight in a windless lab at 20 m ASL, Obstacle Avoidance Off, from 100% to 0% battery. Results vary by environment and firmware. |
| Max Hovering Time |
47 min
Measured hovering in a windless environment at 20 m ASL from 100% to 0% battery. Results vary. |
| Max Flight Distance |
43 km
Measured at 16 m/s in a windless environment at 20 m ASL from 100% to 0% battery. Results vary. |
| Max Wind Speed Resistance |
12 m/s*
* Max wind speed resistance during takeoff and landing. |
| Max Pitch Angle |
25° (Normal Mode)
30 (Sport Mode°) |
| Operating Temperature |
-20° to 50° C (-4° to 122° F) |
| GNSS |
GPS + BeiDou + Galileo + QZSS + GLONASS
QZSS and GLONASS supported only with RTK enabled |
| Max Angular Velocity |
200°/s |
| Hovering Accuracy Range |
Vertical:
±0.1 m (Vision Positioning)
±0.5 m (GNSS)
±0.1 m (RTK)
Horizontal:
±0.3 m (Vision Positioning)
±0.5 m (GNSS)
±0.1 m (RTK) |
| Ingress Protection Rating |
IP55 |
| Motor Model |
2611 |
| Propeller Model |
1364F foldable low-noise anti-ice propellers |
| RTK Module |
Integrated on the aircraft |
| Beacon |
Integrated on the aircraft |
| Camera |
|
Image Sensor |
Wide:
Wide-Angle: 4/3 CMOS, 20 MP
Medium Tele Camera:
1/1.3-inch CMOS, Effective Pixels: 48 MP
Telephoto:
1/1.5-inch CMOS, Effective Pixels: 48 MP |
| Lens |
Wide Angle
FOV: 82°
Equivalent Focal Length: 24 mm
Aperture: f/1.7
Focus: 1 m to ∞
Medium Tele
FOV: 35°; 70 mm equivalent; f/2.8; Focus: 3 m–∞
Tele
FOV: 15°; 168 mm equivalent; f/2.8; Focus: 3 m–∞
Lens Defogging: Supported on wide-angle, medium tele, and tele |
| ISO Range |
Normal Mode: ISO 100 to ISO 25600
Night Scene Mode:
Wide Camera: ISO 100 to ISO 409600
Medium Tele Camera: ISO 100 to ISO 409600
Tele Camera: ISO 100 to ISO 819200 |
| Shutter Speed |
2-1/8000 s |
| Max Photo Size |
Wide: 8064 × 6048
Medium Telephoto: 8064 × 6048
Telephoto: 8192 × 6144 |
| Minimum Photo Interval |
0.7 s |
| Still Photography Modes |
Wide-Angle: Single (12/48 MP), Timed, Smart Capture, Panorama
Medium Tele: Single (12/48 MP), Timed, Smart Capture
Tele: Single (12/48 MP), Timed, Smart Capture |
| Video Codec and Resolution |
H.264 / H.265, CBR or VBR
4K: 3840×2160@30fps
FHD: 1920×1080@30fps |
| Max Video Bitrate |
H.264: 60Mbps
H.265: 40Mbps |
| Supported File System |
exFAT |
| Photo Format |
JPEG |
| Video Format |
MP4 (MPEG-4 AVC/H.264) |
| Digital Zoom |
Telephoto:16x (112x hybrid zoom) |
| NIR Auxiliary Light |
|
Infrared Illumination |
DJI Matrice 4T:
FOV: 5.7°±0.3° |
| Laser Module |
| Laser Rangefinding |
Laser Rangefinding Normal Incidence: 1800 m @20% reflectivity target (1 Hz)
Oblique Incidence (1:5): 600 m (1 Hz)
Blind Zone: 1 m
Distance Accuracy (1–3 m range): System Error <0.3 m, Random Error <0.1 m @1σ
Other Distances: ±(0.2 + 0.0015D) (D in meters)
*Performance may degrade in rain or fog. |
| Infrared Thermal Camera |
|
Thermal Imager |
Uncooled VOx Microbolometer
Do not expose lenses to intense energy (sun, lava, lasers) to avoid permanent damage.
|
| Resolution |
640 × 512 (UHR up to 1280×1024@30fps) |
| Pixel Pitch |
12 μm |
| Frame Rate |
30 Hz |
| Lens |
DFOV: 45°±0.3°
Equivalent focal length: 53 mm
Aperture: f/1.0
Focus: 5 m to ∞ |
| Sensitivity |
≤50mk@F1.0 |
| Temperature Measurement |
Spot & Area
High Gain Mode: -20℃ to 150℃ (-4°F to 302°F) ()
Low Gain Mode: 0℃ to 550℃ (32°F to 1022°F) |
| Palette |
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2 |
| Photo Format |
JPEG (8bit), R-JPEG (16bit) |
| Video Resolution |
1280 × 1024@30fps (Super Resolution enabled, Night Mode not activated)
Other conditions: 640 × 512@30fps |
| Video Bitrate |
6.5Mbps (H.264 640 × 512@30fps)
5Mbps (H.265 640 × 512@30fps)
12Mbps (H.264 1280 × 1024@30fps)
8Mbps (H.265 1280 × 1024@30fps) |
| Video Format |
MP4 |
| Still Photography Modes |
Single (640×512 or 1280×1024), Timed (0.7–60 s intervals), UHR Infrared Image |
| Digital Zoom |
28x |
| Infrared Wavelength |
8um to 14um |
| Infrared Temperature Measurement Accuracy |
High Gain: ±2℃ or ±2%, whichever is greater
Low Gain: ±5℃ or ±3%, whichever is greater |
| Gimbal |
|
Stabilization System |
3-axis mechanical (tilt, roll, pan) |
| Mechanical Range |
Tilt: -140° to +113°; Roll: -52° to +52°; Pan: -65° to +65° |
| Controllable Rotation Range |
Pan: ±-90° to 35°
Pan: Not controllable |
| Max Control Speed (tilt) |
100°/s |
| Angular Vibration Range |
±0.005° |
| Sensing |
|
Sensing Type |
Omnidirectional binocular vision + 3D infrared sensor (downward) |
| Forward |
Measurement: 0.5–20 m
Detection: 0.5–200 m
Effective Speed: ≤15 m/s
FOV: Horizontal 95°, Vertical 90° |
| Backward |
Measurement: 0.5–20 m
Effective Speed: ≤12 m/s
FOV: Horizontal 95°, Vertical 90° |
| Lateral |
Measurement: 0.5–16 m
Effective Speed: ≤10 m/s
FOV: Horizontal 90°, Vertical 90° |
| Downward |
Measurement: 0.5–16 m
Effective Speed: ≤6 m/s
FOV: Front/Back 90°, Left/Right 95° |
| Operating Environment |
Forward/Backward/Upward/Downward: Surfaces with clear patterns,
lux >0.1
Lateral: Diffuse reflective surface >20% reflectivity, lux >6 |
| Video Transmission |
|
Video Transmission System |
DJI O4+ Enterprise |
| Live View Quality |
720p/30fps or 1080p/30fps (DJI RC Plus 2 Enterprise)
540p/30fps, 720p/30fps, 1080p/30fps (DJI Dock 3 & FlightHub 2) |
| Operating Frequency |
2.400–2.4835 GHz 5.150–5.250 GHz (CE: 5.170–5.250 GHz) 5.725–5.850 GHz Availability varies by region; comply with local regulations.
|
| Transmitter Power (EIRP) |
2.4 GHz: ≤33 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dB (SRRC) , <14 dBm (CE)
5.15-5.25: < 23 dBm (FCC/CE) |
| Max Transmission Distance (unobstructed, free of interference) |
25 km (FCC)
12 km (CE)
12 km (SRRC)
12 km (MIC)
Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminder on the DJI Pilot 2 app. |
| Max Transmission Distance (with interference) |
Strong Interference - City Centers (approx. 1.5-5 km)
Medium Interference - Suburban Areas (approx. 5-15 km)
Micro interference：Suburbs/Seasides (approx. 15-25 km)
* Data is tested under FCC standards in unobstructed environments of typical interference. Only to serve as a reference and provides no guarantee as to the actual flight distance. |
| Max Download Speed |
20 MB/s (DJI Dock 3), 20 MB/s (DJI RC Plus 2 Enterprise) |
| Latency (depending on environmental conditions and mobile device) |
~100 ms aircraft to dock (dependent on environment), additional network factors for dock to FlightHub 2 |
| Antenna |
8 antennas, 2T4R |
| Others |
Supports DJI Cellular Dongle 2 (region-dependent) |
